When Performance Is Non-Negotiable, You Need a Material That Delivers
Every gram saved. Every megapascal of strength. Every thermal cycle survived.
These are the metrics that define success in aerospace, automotive, motorsports, and high-end manufacturing. You cannot afford a reinforcement material that underperforms, delaminates, or varies from batch to batch.
Carbon Fiber Cloth from our factory is engineered for exactly this standard. Whether you’re laying up drone frames, compression-molding automotive components, or reinforcing concrete structures, our Carbon Fiber Cloth gives you the consistency, strength, and processability your production demands.
We are not a trading company. We are a specialized manufacturer of carbon fiber textiles, supplying OEMs, composite fabricators, and industrial distributors in over 30 countries. Every roll of Carbon Fiber Cloth is woven, inspected, and packaged under strict quality control—so you can build with confidence.
Technical Data: Know Exactly What You’re Getting
| Parameter | Standard Range |
|---|---|
| Weave Style | Plain, 2×2 Twill, 4-HS Satin, 8-HS Satin, Unidirectional |
| Yarn Type | 1K, 3K, 6K, 12K carbon fiber |
| Areal Weight | 90 gsm – 600 gsm |
| Thickness | 0.10 mm – 0.65 mm |
| Roll Width | 100 cm, 125 cm, 150 cm (custom slitting available) |
| Roll Length | 50 m, 100 m, 200 m (custom lengths) |
| Tensile Strength (fiber) | ≥ 4900 MPa |
| Tensile Modulus (fiber) | ≥ 230 GPa |
| Fiber Density | 1.8 g/cm³ |
| Sizing | Epoxy, vinyl ester, polyester, phenolic, or unsized |
| Color | Natural black |
This is the baseline. Your application may require something different—we manufacture to your spec.
The Right Carbon Fiber Cloth for Every Process
Different molding methods demand different fabric characteristics. Here’s how to select the right Carbon Fiber Cloth for your process:
Hand Lay-Up — Choose a 2×2 twill or plain weave in 200–300 gsm. The fabric drapes easily, wets out quickly, and conforms to moderate curves without bridging.
Vacuum Infusion — A 300–400 gsm twill or satin weave offers the right balance of permeability and mechanical properties. The open weave structure allows resin to flow evenly without dry spots.
Resin Transfer Molding (RTM) — Select a 200–400 gsm fabric with a stable weave pattern to withstand injection pressure without fiber wash. Satin weaves are preferred for complex geometries.
Compression Molding — Unidirectional or hybrid Carbon Fiber Cloth in 150–300 gsm layers provides predictable ply stacking and uniform thickness control.
Prepreg Processing — Choose a tightly controlled areal weight (e.g., 120 gsm, 200 gsm, 240 gsm) with sizing matched to the prepreg resin system. We can supply exact-width slitting for automated tape laying.
Not sure which Carbon Fiber Cloth suits your line? Our engineers will review your process parameters and recommend the optimal specification—free of charge.
What Separates Our Carbon Fiber Cloth From Standard Supplier Stock
1. Controlled Fiber Alignment
Woven on precision looms with real-time tension monitoring. Every meter of Carbon Fiber Cloth maintains uniform tow spacing and fiber orientation. This means fewer weak points, predictable mechanical properties, and less scrap.
2. Clean, Fray-Free Edges
Our slitting process produces edges that don’t unravel during handling or cutting. For high-volume production, this reduces downtime and improves lay-up consistency.
3. Resin-Optimized Sizing
Generic sizing works okay with most resins. Our Carbon Fiber Cloth is available with sizing agents specifically formulated for epoxy, vinyl ester, or phenolic systems. Better wet-out means better interlaminar shear strength and fewer voids.
4. Full Traceability
Every roll carries a unique batch number. We provide material certificates, mechanical test reports, and compliance documentation. Your QA team will have the records they need for audits and end-customer assurance.
5. Consistent Global Supply
With in-house weaving and finishing, we control lead times and quality. No dependency on third-party converters. No surprise delays. You receive the same Carbon Fiber Cloth quality whether you order one roll or a full container.
Industries We Currently Supply
Aerospace & UAV
Wing skins, fuselage panels, internal structures, drone airframes. Carbon Fiber Cloth delivers the stiffness-to-weight ratio required for flight efficiency and payload performance.
Automotive & Motorsports
Body panels, structural tubs, crash structures, interior components. Teams and OEMs use our Carbon Fiber Cloth to cut vehicle mass while meeting impact and durability standards.
Sporting Goods
Bicycle frames, hockey sticks, rackets, fishing rods, protective gear. The vibration damping and fatigue resistance of Carbon Fiber Cloth translate directly into performance and product life.
Marine
Masts, hulls, deck fittings, hydrofoils. Saltwater corrosion is not a problem for Carbon Fiber Cloth—unlike metals that require coatings and sacrificial anodes.
Civil Engineering & Industrial
Structural reinforcement for bridges, columns, and pressure vessels. Carbon Fiber Cloth is wrapped around existing structures to add strength without adding weight or bulk.
Consumer Electronics & Medical
Laptop shells, gimbal arms, prosthetics, imaging equipment. Thin, lightweight Carbon Fiber Cloth offers both mechanical performance and a premium appearance.
Custom Manufacturing Capabilities
Standard catalogs don’t fit every project. We offer full customization for Carbon Fiber Cloth:
-
Custom weave patterns — spread tow, unidirectional, hybrid with aramid or glass
-
Non-standard widths — slit to ±1 mm tolerance
-
Special roll lengths — matched to your cutting table or automation system
-
Surface treatments — plasma, corona, or specialty coatings
-
Pre-cut shapes — die-cut or CNC-cut kits ready for lay-up
-
Private labeling — your brand on rolls, boxes, and documentation
Send us your spec. We’ll respond with a proposal within 24 hours, including feasibility, pricing, and lead time.
Packaging & Global Delivery
Carbon Fiber Cloth is hygroscopic and sensitive to contamination. Our packaging reflects that:
-
Moisture-proof barrier film on every roll
-
Cardboard tubes or cores to prevent creasing
-
Foam end caps for edge protection
-
Reinforced export cartons or wooden crates
-
Full shipment insurance and documentation
We ship worldwide via air freight, sea freight, or express courier. Standard items ship in 3–5 working days. Custom orders typically require 10–20 working days depending on volume and complexity.
Answers to Questions We Get From B2B Buyers
Q: Can you match a competitor’s specification?
A: Yes. Send us the datasheet or a physical sample, and we will reverse-engineer the weave, areal weight, and sizing to produce a comparable or superior Carbon Fiber Cloth.
Q: Do you offer trial quantities?
A: Absolutely. We encourage first-time buyers to order a single roll for process validation before committing to larger volumes. Samples are available free of charge for qualified B2B customers.
Q: What is your quality standard?
A: Our factory operates under ISO 9001. Every batch of Carbon Fiber Cloth is tested for areal weight, thickness, tensile strength, and visual defects before release.
Q: Can you hold inventory for scheduled releases?
A: Yes. For OEM customers with long-term contracts, we offer vendor-managed inventory and scheduled deliveries to match your production planning.
Q: What are your payment terms?
A: Standard terms are T/T (bank transfer). For established customers, we offer flexible options including L/C at sight and net terms subject to credit approval.
Build With a Carbon Fiber Cloth Supplier You Can Trust
Your products are only as good as the materials that go into them. Partner with a manufacturer that understands the difference between “good enough” and “engineered to spec.”
Our team has years of experience supplying Carbon Fiber Cloth to industries where failure is not an option. Let us help you select the right specification, validate your process, and scale your production with confidence.
