Our carbon fiber packing is engineered for demanding sealing applications in valves and pumps across chemical, petrochemical, and power industries. This high pressure carbon fiber packing combines a carbon fiber core, PTFE corrosion barrier, and graphite lubricant to deliver reliable performance where conventional packing fails. Whether you need corrosion resistant carbon fiber packing for acid service or carbon fiber braided packing for high-speed rotating shafts, our product line offers a grade to match your operating conditions.
Applications of Carbon Fiber Packing – Critical Applications
| Application | Key Challenge | Our Solution |
| Chemical & Petrochemical Plants | Sulfuric acid, caustic soda, organic solvents | Carbon fiber core + PTFE barrier resists pH 0–14 |
| High-Pressure Valves & Pumps | Seal collapse at 40+ MPa | Dynamic compression recovery maintains sealing force |
| Offshore & Subsea Equipment | Saltwater corrosion, deep-sea pressures | Non-galling, salt-resistant grade available |
| Pharmaceutical & Food Processing | Zero contamination, FDA compliance | FDA-compliant PTFE grades for sanitary applications |
Learn more about industry-specific grades →
Why Choose Our Carbon Fiber Packing
Triple-Layer Construction – Carbon fiber core provides strength up to 550°C; PTFE barrier resists pH 0–14; graphite lubricant reduces friction by 35% compared to standard packing.
Pressure-Adaptive Recovery – Lab-tested to maintain 95% sealing force after 10,000 pressure cycles (simulating valve actuation).
Zero Contamination – Non-galling design passes API 622 particulate emission tests at <100 ppm.
Certified Performance – Exceeds ISO 15848-2 tightness class B by 30% in independent third-party testing.
Certifications & Trust
Certified by Lloyd’s Register & ATEX for explosive environments
ISO 9001:2015 manufacturing facility
Supports custom formulations for unique chemical/thermal profiles
Lab reports available on request
Available in 8 Industry-Specific Grades
Download Chemical Resistance Guide (PDF) — material selection chart for acids, alkalis, and solvents.
Request a Quote – Send Your Specs — get a same-day response from our engineering team.
Talk to an Engineer – WhatsApp — direct line for technical questions.
Technical Specifications
<a name=”technical-specifications”></a>
| Grade | Temperature Range | Pressure Rating | pH Range | Shaft Speed | Typical Applications |
| CF-100 | -50°C to 280°C | 20 MPa | 0–14 | 15 m/s | General chemical service |
| CF-200 | -100°C to 450°C | 40 MPa | 0–14 | 20 m/s | High pressure valves, boiler feed pumps |
| CF-400 | -200°C to 550°C | 60 MPa | 1–13 | 25 m/s | Extreme temperature cycling, refinery service |
| CF-FDA | -50°C to 260°C | 15 MPa | 3–11 | 10 m/s | Food, pharmaceutical, sanitary lines |
Custom grades available for unique chemical/thermal profiles. Contact our lab for formulation testing.
Common Dimensions for Braided Packing
| Cross Section (mm) | Spool Length (m) | Weight per Spool (kg) |
| 3 × 3 | 8 | 0.5 |
| 5 × 5 | 8 | 1.0 |
| 6 × 6 | 5 | 1.2 |
| 8 × 8 | 5 | 2.0 |
| 10 × 10 | 5 | 3.0 |
| 12 × 12 | 3 | 3.5 |
| 16 × 16 | 3 | 5.0 |
Custom sizes and spool lengths available. Minimum order quantity: 10 kg for standard grades.
Braided Packing Selection Guide
Not sure which grade to choose? Use our Braided Packing Selection Guide to match the right packing to your operating conditions, or send us your process data and we’ll recommend a grade.
Frequently Asked Questions
Q: What is the maximum pressure rating for carbon fiber braided packing?
A: Our CF-400 grade is rated up to 60 MPa, while CF-200 is rated for 40 MPa. The actual pressure capacity depends on shaft speed, temperature, and media compatibility. Contact us with your operating conditions for a specific recommendation.
Q: Can this packing be used with sulfuric acid?
A: Yes. The PTFE corrosion barrier provides excellent resistance to concentrated sulfuric acid at temperatures up to 200°C. For higher concentrations or temperatures, we recommend the CF-400 grade or a custom formulation.
Q: Do you offer FDA-compliant grades for food processing?
A: Yes, our CF-FDA grade uses FDA-compliant PTFE and lubricants. It is suitable for sanitary pumps and valves in food and pharmaceutical applications.
Q: What is the difference between carbon fiber and graphite packing?
A: Carbon fiber packing has a fibrous structure that provides better mechanical strength and resilience under high pressure. Graphite packing is softer and more conformable but has lower tensile strength. Our carbon fiber packing includes a graphite lubricant layer to combine both benefits.
Q: How do I select the correct braided packing size for my pump shaft?
A: Measure the stuffing box depth and subtract the gland follower length. The packing cross-section should be slightly smaller than the gap between the shaft and the stuffing box wall. Our selection guide provides a detailed step-by-step process.
Get a Quote for Your Application
Send us your operating conditions (pressure, temperature, media, shaft size) and we’ll provide a material recommendation and quotation within 24 hours.
